| Model | LNK4024GP Series |
| Ports | 24*10/100/1000M PoE RJ45 ports |
| 4*10G SFP+ ports |
| Management port | 1x Console port |
| Reset key | 1x Reset key, for restore default settings |
| Switching Capacity | 598G |
| PoE Feature | IEEE802.3af/at Support PoE management, PoE schedule, Information of PoE status. |
| Packet Forwarding Rate | 95Mpps @ 64byts |
| Operating temperature | -20~+55°C |
| Input voltage | AC: 110～240V/50～60Hz |
| Total power consumption | LNK-L4024GPF: 400W LNK-L4024GPT: 600W |
| Protocol & Standard | IEEE 802.3,10BASE-T Ethernet; |
| IEEE 802.3u, fast Ethernet Standard; |
| IEEE 802.3ab, gigabit Ethernet Standard; |
| IEEE 802.3z, gigabit Ethernet Fiber Standard;(AOC fiber cable) |
| IEEE 802.3ae,10G Ethernet Standard; |
| IEEE 802.3x, full-duplex Ethernet data link layer flow control; |
| MAC | 32K |
| supports automatic updates, two-way learning; |
| SRAM Buffer | 32Mb |
| Route Function | Max support 144 IPv4/IPv6 static routes or default routes |
| ARP | Max support 256 dynamic ARP |
| DHCP | DHCP Client, DHCP Snooping |
| VLAN | Support up to 4K VLAN; |
| Support port-based VLAN; |
|
| Support 802.1Q tag-based VLAN; |
| Spanning Tree | STP, RSTP, MSTP |
| Port Aggregation (TRUNK) | Support 4x 10G ports aggregation, support 32x Gigabit ports aggregation |
| Support 16x groups aggregation |
| Port Mirroring | Support multiple to single Port mirroring, no limit for quantity of mirroring source ports |
| Port Isolation | Support downstream ports isolated from each other, while opening communication with upstream ports |
| Port Flow Control | Support half-duplex back pressure based control; |
| Support full-duplex PAUSE frame based control; |
| Port Speed Limit | Support port-based input/output bandwidth management |
| Storm Control | Prevents traffic on a LAN from being disrupted by a broadcast, multicast, or unicast storm on a port |
| Support port storm threshold setting |
| Security Features | Hardware support port-based IP+MAC Binding; Hardware support port-based ARP inspection detection; |
| QOS | SP (Strict Priority); |
| WFQ (Weighted Fair Queuing); |
| WRR (Weighted Round Robin); |
| Head Of Line; |
| Best-Effort Service; |
| First come first served; |
| 802.1p; |
| Cos/Tos, QOS; |
| Differentiated Service; |
| Network Cable Line Sequence | Support Auto-MDIX, automatic Identification straight-through cable and crossover cable |
| cable diagnosis | Support cable diagnosis, Cable quality (differential pair impedance 85ohm ~ 125ohm), cable length, a short-circuit line |
| Negotiation Mode | Support port auto-negotiation function (auto-negotiation transmission rate and duplex mode) |
|  System Maintenance
| Support configuration file upload/download; |
| Support update packet upload; |
| Support WEB reset; |
| Reset by pressing key; |
| Support system log save/output; |
| Network Management | Support WEB management ; |
| Support CLI management ; |
